2021 Nexus RV Wraith 35w Specs
Know Before You Drive
Key specs for safe motorhome driving
⚠️ Height Alert: Over 11' tall. Watch for low bridges and overhangs!
Compact
<14k
Mid-Size
14-20k
Large
20-26k
XL
26k+
DRIVING QUICK FACTS
GVWR
24,500 lbs
License
Check state requirements
Type
Class C
License Requirement
Check state requirements
Standard
Check State
CDL May Apply
Essential Upgrades for the 2021 Nexus RV Wraith 35w
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 24500 lbs | - | - | - |
| Length | 433 in | Furrion Backup Camera | Shop Cameras | - |
| Width | 101 in | Clip On Mirrors | Shop Mirrors | - |
| Exterior Height | 150 in | Telescoping Ladder | Shop Ladders | - |
| Towing Capacity | 10000 / 4536 lbs | - | - | - |
Specs
Buy Now
More
GVWR
24500 lbs
Length
433 in
Width
101 in
Exterior Height
150 in
Towing Capacity
10000 / 4536 lbs
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Converter Amps | 60 | - | - | - |
| Shore Power | 30 Amps | - | - | - |
| Battery Type | 12V Lead-Acid | Renogy 100Ah LiFePO4 | RV Batteries | Top 5 |
| Solar Pre-Wired | Optional | - | - | - |
| Inverter | Optional | - | - | - |
Specs
Buy Now
More
Battery Converter Amps
60
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | - | - |
| Number Of Gray Water Holding Tanks | 1 | - | - | - |
| Number Of Black Water Holding Tanks | 1 | - | - | - |
| Fresh Water Tank Capacity | 77 gal | - | Fresh Water Tanks | - |
| Gray Water Tank Capacity | 43 gal | - | - | - |
| Black Water Tank Capacity | 43 gal | - | Back Water Tanks | - |
| Number Of Propane Tanks | 1 | - | - | - |
| Propane Tank Capacity | 86.1 lbs | - | Propane Tank Capacity | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Number Of Gray Water Holding Tanks
1
Number Of Black Water Holding Tanks
1
Fresh Water Tank Capacity
77 gal
Gray Water Tank Capacity
43 gal
Black Water Tank Capacity
43 gal
Number Of Propane Tanks
1
Propane Tank Capacity
86.1 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Front Wheel Diameter | 22.5 | - | - | - |
| Wheels Composition | Aluminum | - | - | - |
| Front Tire | 22.5-Inch Tires Full Spec | - | - | - |
| Rear Tire | 22.5-Inch Tires Full Spec | - | - | - |
| Front Brake Type | Hydraulic Disc | - | - | - |
| Rear Wheel Diameter | 22.5 | - | - | - |
| Rear Brake Type | Hydraulic Disc | - | - | - |
Specs
Buy Now
More
Front Wheel Diameter
22.5
Wheels Composition
Aluminum
Front Tire
22.5-Inch Tires Full Spec
Rear Tire
22.5-Inch Tires Full Spec
Front Brake Type
Hydraulic Disc
Rear Wheel Diameter
22.5
Rear Brake Type
Hydraulic Disc
Heating & Cooling
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Air Conditioning Type | Automatic | Dometic 13.5K Air Conditioner | Shop All RV AC | - |
| Water Heater Tank Capacity | 6 g | RV Tank Water Heater | RV Water Heaters | - |
| Heater Type | Automatic | - | - | - |
| Water Heater Pump Power Mode | Electrical / Propane | - | - | - |
Specs
Buy Now
More
Air Conditioning Type
Automatic
Water Heater Tank Capacity
6 g
Heater Type
Automatic
Water Heater Pump Power Mode
Electrical / Propane
Heating & Cooling Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Sofa Material | Vinyl | - | - | - |
| Number Of Bunk Beds | 2 | - | - | - |
| Living Area Location | Front | - | - | - |
| Master Bedroom Flooring Type | Vinyl | - | - | - |
| Master Bedroom Mirror Doors | Yes | - | - | - |
| Number Of Full Size Beds | 1 | - | - | - |
| Number Of Sofas | 1 | Tri-Fold Sofa | - | - |
| Number Of Bathrooms | 1 | - | - | - |
| Master Bedroom Door Style | Full Sliding Door | - | - | - |
| Number Of Convertible / Sofa Beds | 2 | - | - | - |
| Number Of Recliner / Rockers | 1 | - | - | - |
| Master Bedroom Location | Rear | - | - | - |
| Reclining Sofa | No | RV Loveseat Recliner Sofa | Shop Sofa | - |
| Master Bedroom Shades / Curtains | Yes | - | - | - |
| Number Of Queen Size Beds | 1 | Queen RV Mattress | Shop Mattresses | - |
Specs
Buy Now
More
Sofa Material
Vinyl
Number Of Bunk Beds
2
Living Area Location
Front
Master Bedroom Flooring Type
Vinyl
Master Bedroom Mirror Doors
Yes
Number Of Full Size Beds
1
Number Of Sofas
1
Number Of Bathrooms
1
Master Bedroom Door Style
Full Sliding Door
Number Of Convertible / Sofa Beds
2
Number Of Recliner / Rockers
1
Master Bedroom Location
Rear
Reclining Sofa
No
Master Bedroom Shades / Curtains
Yes
Number Of Queen Size Beds
1
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Kitchen Location | Center | - | - | - |
| Number Of Oven Burners | 3 | - | - | - |
| Kitchen / Living Area Flooring Type | Vinyl | - | - | - |
| Refrigerator Size | Mid-Size | - | - | - |
| Kitchen Table Configuration | Bench Seats | - | - | - |
| Refrigerator Power Mode | Electric | - | - | - |
Specs
Buy Now
More
Kitchen Location
Center
Number Of Oven Burners
3
Kitchen / Living Area Flooring Type
Vinyl
Refrigerator Size
Mid-Size
Kitchen Table Configuration
Bench Seats
Refrigerator Power Mode
Electric
Bathroom
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Bathroom Location | Center | - | - | - |
| Bathroom Flooring Type | Vinyl | - | - | - |
| Toilet Type | Porcelain | RV Toilet with Sprayer Attachment | Toilets | Top 5 |
Specs
Buy Now
More
Bathroom Location
Center
Bathroom Flooring Type
Vinyl
Toilet Type
Porcelain
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number of Awnings | 1 | Motorized RV Awning Set | Shop Awnings | - |
| Leveling Jack Type | Front Power / Rear Power | - | - | - |
| Number Of Axles | 1 | - | - | - |
| Sidewall Construction | Fiberglass | - | - | - |
| Number Of Emergency Exits | 1 | - | - | - |
| Number of Doors | 1 | - | - | - |
| Door Type | Plastic / Glass | - | - | - |
| Body Material | Steel | - | - | - |
Specs
Buy Now
More
Number of Awnings
1
Leveling Jack Type
Front Power / Rear Power
Number Of Axles
1
Sidewall Construction
Fiberglass
Number Of Emergency Exits
1
Number of Doors
1
Door Type
Plastic / Glass
Body Material
Steel
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Power Retractable Awning | Yes | - | - | - |
| Sliding Glass Door | No | - | - | - |
| Heated | No | - | - | - |
| Satellite Prewiring | Yes | - | - | - |
| Bunkhouse | Yes | - | - | - |
| Washer / Dryer Prewiring | No | - | - | - |
| Overhead Fan | Yes | Overhead Fan | - | - |
| Reclining Seats | No | - | - | - |
| Turbocharged | Yes | - | - | - |
| Seat Armrests | Yes | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Power Adjustable Seat | Yes | - | - | - |
| Refrigerator | Standard | - | - | - |
| Battery Power Converter | Yes | - | - | - |
| Wallpaper | Yes | - | - | - |
| Overdrive | Yes | - | - | - |
| Power Retractable Slideout | Yes | - | - | - |
| Supercharged | No | - | - | - |
| Interior Wood Finish | Yes | - | - | - |
| Screened Room | No | - | - | - |
| Cable Prewiring | Yes | - | - | - |
| Water Heater Tank Bypass | Yes | - | - | - |
| Phone Prewiring | No | - | - | - |
| Air Conditioning Prewiring | Yes | - | - | - |
| TV Antenna Prewiring | Yes | - | - | - |
Specs
Buy Now
More
Power Retractable Awning
Yes
Sliding Glass Door
No
Heated
No
Satellite Prewiring
Yes
Bunkhouse
Yes
Washer / Dryer Prewiring
No
Overhead Fan
Yes
Reclining Seats
No
Turbocharged
Yes
Seat Armrests
Yes
Heat Prewiring
Yes
Power Adjustable Seat
Yes
Refrigerator
Standard
Battery Power Converter
Yes
Wallpaper
Yes
Overdrive
Yes
Power Retractable Slideout
Yes
Supercharged
No
Interior Wood Finish
Yes
Screened Room
No
Cable Prewiring
Yes
Water Heater Tank Bypass
Yes
Phone Prewiring
No
Air Conditioning Prewiring
Yes
TV Antenna Prewiring
Yes
Cabin Specs
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Seats | 2 | - | - | - |
| Seat Type | Bucket | - | - | - |
| Seat Specifications | Standard | - | - | - |
| Number Of Rows | 1 | - | - | - |
| Seat Material | Vinyl | - | - | - |
Specs
Buy Now
More
Number Of Seats
2
Seat Type
Bucket
Seat Specifications
Standard
Number Of Rows
1
Seat Material
Vinyl
Chasis
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Chassis Brand | International | - | - | - |
| Chassis Model | DuraStar | - | - | - |
Specs
Buy Now
More
Chassis Brand
International
Chassis Model
DuraStar
Drivetrain
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Transmission Type | Automatic | - | - | - |
| Driveline Type | 4X2 | - | - | - |
| Transmission Brand | Allison | - | - | - |
| Number Of Speeds | 6 | - | - | - |
Specs
Buy Now
More
Transmission Type
Automatic
Driveline Type
4X2
Transmission Brand
Allison
Number Of Speeds
6
Engine
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Cylinders | 6 | - | - | - |
| Torque | 895 Nm | - | - | - |
| Engine Type | I6 | - | - | - |
| Carburetion Type | Fuel Injected | - | - | - |
| Carburetion | Standard | - | - | - |
| Torque RPM | 1600 | - | - | - |
| Engine Brand Name | Cummins | - | - | - |
| Horsepower | 300 bhp | - | - | - |
| Horsepower RPM | 2600 | - | - | - |
Specs
Buy Now
More
Cylinders
6
Torque
895 Nm
Engine Type
I6
Carburetion Type
Fuel Injected
Carburetion
Standard
Torque RPM
1600
Engine Brand Name
Cummins
Horsepower
300 bhp
Horsepower RPM
2600
Entertainment
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Discs | 1 | - | - | - |
| Speaker Location | Interior | RecPro Exterior Speakers | - | - |
| Number Of Televisions | 1 | Insignia LED HD Alexa TV | Shop RV TV's | - |
Specs
Buy Now
More
Number Of Discs
1
Speaker Location
Interior
Number Of Televisions
1
Entertainment Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Fuel & MPG
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Fuel Capacity | 70 / 265 gal/l | 5Gal Gas Can | - | - |
| Fuel Type | Diesel | Fuel Treatment | - | - |
Specs
Buy Now
More
Fuel Capacity
70 / 265 gal/l
Fuel Type
Diesel
Fuel & MPG Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Instrumentation
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Radios | 1 | - | - | - |
Specs
Buy Now
More
Number Of Radios
1
Interior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Material | Vinyl | - | - | - |
Specs
Buy Now
More
Material
Vinyl
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Nexus RV | - | - | - |
| Year | 2021 | - | - | - |
| Make | NeXus RV | - | - | - |
| Display Name | Wraith 35W | - | - | - |
| Class | Class C | - | - | - |
| Max Sleeping Count | 10 | - | - | - |
| Number of Slideouts | 2 | - | - | - |
| Introduction Year | 2018 | - | - | - |
Specs
Buy Now
More
Parent Company
Nexus RV
Year
2021
Make
NeXus RV
Display Name
Wraith 35W
Class
Class C
Max Sleeping Count
10
Number of Slideouts
2
Introduction Year
2018
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this class c.
Drivability & Handling
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+0.0
Final Drivability & Handling
5.0
Living Space & Layout
5.3/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+0.3
Final Living Space & Layout
5.3
Comfort & Features
5.8/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+0.8
Final Comfort & Features
5.8
Storage Space
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+0.0
Final Storage Space
5.0
Off-Grid & Campsites
6.3/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+1.3
Final Off-Grid & Campsites
6.3
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2021 Nexus RV Wraith 35w, ensure your vehicle's rated tow capacity exceeds its GVWR of 24500 lbs. With a dry weight of lbs and hitch weight of lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Class C has a dry weight of lbs and a GVWR of 24500 lbs, giving a payload capacity of lbs for gear, water, and supplies.
The approximate dimensions are length 433 in., width 101 in., and height 150 in. Always confirm clearances for garages, storage, and campsites.
The Wraith 35w includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many Wraith 35w owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 24500 lbs and dry weight of lbs, the Wraith 35w is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 10 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Class C.
The Wraith 35w features body construction with sidewalls and 1 axle(s). Its GVWR of 24500 lbs ensures strength without excessive towing weight.
?? Tip: Always check your vehicle's specific towing capacity in the owner's manual. Consider payload and tongue weight too!
As an Amazon Associate, we may earn from qualifying purchases. Your price stays the same.
"Our mission at Mint RV is to help people make well-informed RV buying decisions, so they can escape the stress of everyday life, reconnect with family, and create unforgettable memories in the great outdoors"
