2017 Thor Motor Coach Palazzo 33-4 Specs
Know Before You Drive
Key specs for safe motorhome driving
⚠️ Height Alert: Over 11' tall. Watch for low bridges and overhangs!
Compact
<14k
Mid-Size
14-20k
Large
20-26k
XL
26k+
DRIVING QUICK FACTS
GVWR
26,000 lbs
License
Check state requirements
Type
Class A
License Requirement
Check state requirements
Standard
Check State
CDL May Apply
Essential Upgrades for the 2017 Thor Motor Coach Palazzo 33-4
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 26000 lbs | - | - | - |
| Length | 417 in | Furrion Backup Camera | Shop Cameras | - |
| Width | 101 in | Clip On Mirrors | Shop Mirrors | - |
| Interior Height | 82 in | - | - | - |
| Towing Capacity | 10000 / 4536 lbs | - | - | - |
| Exterior Height | 142 in | Telescoping Ladder | Shop Ladders | - |
Specs
Buy Now
More
GVWR
26000 lbs
Length
417 in
Width
101 in
Interior Height
82 in
Towing Capacity
10000 / 4536 lbs
Exterior Height
142 in
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Converter Amps | 100 | - | - | - |
| Shore Power | 30 Amps | - | - | - |
| Battery Type | 12V Lead-Acid | Renogy 100Ah LiFePO4 | RV Batteries | Top 5 |
| Solar Pre-Wired | Optional | - | - | - |
| Inverter | Optional | - | - | - |
Specs
Buy Now
More
Battery Converter Amps
100
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | - | - |
| Number Of Gray Water Holding Tanks | 1 | - | - | - |
| Number Of Black Water Holding Tanks | 1 | - | - | - |
| Fresh Water Tank Capacity | 95 gal | - | Fresh Water Tanks | - |
| Gray Water Tank Capacity | 43 gal | - | - | - |
| Black Water Tank Capacity | 43 gal | - | Back Water Tanks | - |
| Propane Tank Capacity | 104 lbs | - | Propane Tank Capacity | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Number Of Gray Water Holding Tanks
1
Number Of Black Water Holding Tanks
1
Fresh Water Tank Capacity
95 gal
Gray Water Tank Capacity
43 gal
Black Water Tank Capacity
43 gal
Propane Tank Capacity
104 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Front Brake Type | Hydraulic Drum | - | - | - |
| Wheels Composition | Steel | - | - | - |
| Front Wheel Diameter | 22.5 | - | - | - |
| Rear Wheel Diameter | 22.5 | - | - | - |
| Rear Wheel Width | 8.25 in | - | - | - |
| Front Wheel Width | 8.25 in | - | - | - |
| Wheelbase | 208 / 5283.2 in | - | - | - |
| Front Tire Width | 255 | - | - | - |
| Rear Tire Width | 255 | - | - | - |
| Rear Tire | Michelin® 255/70R 22.5 Full Spec | - | - | - |
| Front Tire | Michelin® 255/70R 22.5 Full Spec | - | - | - |
| Tire Brand | Michelin® | - | - | - |
| Front Tire Aspect Ratio | 70 | - | - | - |
| Rear Tire Aspect Ratio | 70 | - | - | - |
| Rear Brake Type | Hydraulic Drum | - | - | - |
Specs
Buy Now
More
Front Brake Type
Hydraulic Drum
Wheels Composition
Steel
Front Wheel Diameter
22.5
Rear Wheel Diameter
22.5
Rear Wheel Width
8.25 in
Front Wheel Width
8.25 in
Wheelbase
208 / 5283.2 in
Front Tire Width
255
Rear Tire Width
255
Rear Tire
Michelin® 255/70R 22.5 Full Spec
Front Tire
Michelin® 255/70R 22.5 Full Spec
Tire Brand
Michelin®
Front Tire Aspect Ratio
70
Rear Tire Aspect Ratio
70
Rear Brake Type
Hydraulic Drum
Heating & Cooling
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Air Conditioning Type | Automatic | Dometic 13.5K Air Conditioner | Shop All RV AC | - |
| Water Heater Tank Capacity | 10 g | RV Tank Water Heater | RV Water Heaters | - |
| Heater Type | Automatic | - | - | - |
| Water Heater Pump Power Mode | Electrical / Propane | - | - | - |
Specs
Buy Now
More
Air Conditioning Type
Automatic
Water Heater Tank Capacity
10 g
Heater Type
Automatic
Water Heater Pump Power Mode
Electrical / Propane
Heating & Cooling Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Master Bedroom Location | Rear | - | - | - |
| Sofa Material | Vinyl | - | - | - |
| Number Of Convertible / Sofa Beds | 2 | - | - | - |
| Master Bedroom Flooring Type | Vinyl | - | - | - |
| Master Bedroom Shades / Curtains | Yes | - | - | - |
| Number Of Sofas | 1 | Tri-Fold Sofa | - | - |
| Number Of Queen Size Beds | 1 | Queen RV Mattress | Shop Mattresses | - |
| Number Of Bathrooms | 1 | - | - | - |
| Master Bedroom Door Style | Full Sliding Door | - | - | - |
| Master Bedroom Mirror Doors | Yes | - | - | - |
| Living Area Location | Front | - | - | - |
| Full Size Master Bedroom Closet | Yes | - | - | - |
| Number Of Full Size Beds | 1 | - | - | - |
Specs
Buy Now
More
Master Bedroom Location
Rear
Sofa Material
Vinyl
Number Of Convertible / Sofa Beds
2
Master Bedroom Flooring Type
Vinyl
Master Bedroom Shades / Curtains
Yes
Number Of Sofas
1
Number Of Queen Size Beds
1
Number Of Bathrooms
1
Master Bedroom Door Style
Full Sliding Door
Master Bedroom Mirror Doors
Yes
Living Area Location
Front
Full Size Master Bedroom Closet
Yes
Number Of Full Size Beds
1
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Kitchen / Living Area Flooring Type | Vinyl | - | - | - |
| Refrigerator Size | Full-Size | - | - | - |
| Kitchen Table Configuration | Bench Seats | - | - | - |
| Refrigerator Power Mode | Electric / Propane | - | - | - |
| Kitchen Location | Center | - | - | - |
| Number Of Oven Burners | 3 | - | - | - |
Specs
Buy Now
More
Kitchen / Living Area Flooring Type
Vinyl
Refrigerator Size
Full-Size
Kitchen Table Configuration
Bench Seats
Refrigerator Power Mode
Electric / Propane
Kitchen Location
Center
Number Of Oven Burners
3
Bathroom
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Toilet Type | Porcelain | RV Toilet with Sprayer Attachment | Toilets | Top 5 |
| Bathroom Location | Center | - | - | - |
| Bathroom Flooring Type | Vinyl | - | - | - |
Specs
Buy Now
More
Toilet Type
Porcelain
Bathroom Location
Center
Bathroom Flooring Type
Vinyl
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Awning Length | 18 ft/m | Awning Fabric Replacement | All Awnings | - |
| Number of Awnings | 1 | Motorized RV Awning Set | Shop Awnings | - |
| Leveling Jack Type | Front Power / Rear Power | - | - | - |
| Number Of Axles | 1 | - | - | - |
| Sidewall Construction | Fiberglass | - | - | - |
| Number Of Emergency Exits | 1 | - | - | - |
| Number of Doors | 1 | - | - | - |
| Door Type | Plastic / Glass | - | - | - |
| Body Material | Aluminum | - | - | - |
Specs
Buy Now
More
Awning Length
18 ft/m
Number of Awnings
1
Leveling Jack Type
Front Power / Rear Power
Number Of Axles
1
Sidewall Construction
Fiberglass
Number Of Emergency Exits
1
Number of Doors
1
Door Type
Plastic / Glass
Body Material
Aluminum
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Refrigerator | Standard | - | - | - |
| Battery Power Converter | Yes | - | - | - |
| Turbocharged | Yes | - | - | - |
| Metallic | No | - | - | - |
| Supercharged | No | - | - | - |
| Interior Wood Finish | Yes | - | - | - |
| Power Retractable Awning | Yes | - | - | - |
| Screened Room | No | - | - | - |
| Cable Prewiring | Yes | - | - | - |
| Wallpaper | Yes | - | - | - |
| Overhead Fan | Yes | Overhead Fan | - | - |
| Reclining Seats | Yes | - | - | - |
| Air Conditioning Prewiring | Yes | - | - | - |
| Swivel Seats | Yes | - | - | - |
| Sliding Glass Door | No | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Water Heater Tank Bypass | Yes | - | - | - |
| Power Adjustable Seat | Yes | - | - | - |
| Satellite Prewiring | Yes | - | - | - |
| Bunkhouse | No | - | - | - |
| TV Antenna Prewiring | Yes | - | - | - |
| Overdrive | Yes | - | - | - |
| Surround Sound | Yes | - | - | - |
| Power Retractable Slideout | Yes | - | - | - |
| Seat Armrests | Yes | - | - | - |
| Washer / Dryer Prewiring | Yes | - | - | - |
| Phone Prewiring | No | - | - | - |
Specs
Buy Now
More
Refrigerator
Standard
Battery Power Converter
Yes
Turbocharged
Yes
Metallic
No
Supercharged
No
Interior Wood Finish
Yes
Power Retractable Awning
Yes
Screened Room
No
Cable Prewiring
Yes
Wallpaper
Yes
Overhead Fan
Yes
Reclining Seats
Yes
Air Conditioning Prewiring
Yes
Swivel Seats
Yes
Sliding Glass Door
No
Heat Prewiring
Yes
Water Heater Tank Bypass
Yes
Power Adjustable Seat
Yes
Satellite Prewiring
Yes
Bunkhouse
No
TV Antenna Prewiring
Yes
Overdrive
Yes
Surround Sound
Yes
Power Retractable Slideout
Yes
Seat Armrests
Yes
Washer / Dryer Prewiring
Yes
Phone Prewiring
No
Cabin Specs
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Seat Type | Bucket | - | - | - |
| Number Of Rows | 1 | - | - | - |
| Seat Material | Vinyl | - | - | - |
| Seat Specifications | Standard | - | - | - |
| Number Of Seats | 2 | - | - | - |
Specs
Buy Now
More
Seat Type
Bucket
Number Of Rows
1
Seat Material
Vinyl
Seat Specifications
Standard
Number Of Seats
2
Chasis
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Chassis Model | XC-Series | - | - | - |
| Chassis Brand | Freightliner | - | - | - |
Specs
Buy Now
More
Chassis Model
XC-Series
Chassis Brand
Freightliner
Drivetrain
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Transmission Brand | Allison | - | - | - |
| Number Of Speeds | 6 | - | - | - |
| Transmission Type | Automatic | - | - | - |
| Driveline Type | 4X2 | - | - | - |
Specs
Buy Now
More
Transmission Brand
Allison
Number Of Speeds
6
Transmission Type
Automatic
Driveline Type
4X2
Engine
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Carburetion Type | Fuel Injected | - | - | - |
| Torque RPM | 1600 | - | - | - |
| Carburetion | Standard | - | - | - |
| Engine Brand Name | Cummins | - | - | - |
| Torque | 895 Nm | - | - | - |
| Horsepower RPM | 2800 | - | - | - |
| Cylinders | 6 | - | - | - |
| Horsepower | 300 bhp | - | - | - |
| Engine Type | I6 Diesel Pusher | - | - | - |
Specs
Buy Now
More
Carburetion Type
Fuel Injected
Torque RPM
1600
Carburetion
Standard
Engine Brand Name
Cummins
Torque
895 Nm
Horsepower RPM
2800
Cylinders
6
Horsepower
300 bhp
Engine Type
I6 Diesel Pusher
Entertainment
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Speaker Location | Interior | RecPro Exterior Speakers | - | - |
| Number Of Televisions | 3 | Insignia LED HD Alexa TV | Shop RV TV's | - |
| Number Of Discs | 1 | - | - | - |
Specs
Buy Now
More
Speaker Location
Interior
Number Of Televisions
3
Number Of Discs
1
Entertainment Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Fuel & MPG
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Fuel Capacity | 90 / 340.7 gal/l | 5Gal Gas Can | - | - |
| Fuel Type | Diesel | Fuel Treatment | - | - |
Specs
Buy Now
More
Fuel Capacity
90 / 340.7 gal/l
Fuel Type
Diesel
Fuel & MPG Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Instrumentation
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Radios | 1 | - | - | - |
Specs
Buy Now
More
Number Of Radios
1
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Thor Industries | - | - | - |
| Year | 2017 | - | - | - |
| Make | Thor Motor Coach | - | - | - |
| Display Name | Palazzo 33.4 | - | - | - |
| Class | Class A | - | - | - |
| Max Sleeping Count | 8 | - | - | - |
| Number of Slideouts | 3 | - | - | - |
| Introduction Year | 2016 | - | - | - |
Specs
Buy Now
More
Parent Company
Thor Industries
Year
2017
Make
Thor Motor Coach
Display Name
Palazzo 33.4
Class
Class A
Max Sleeping Count
8
Number of Slideouts
3
Introduction Year
2016
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this class a.
Drivability & Handling
6.5/10
Base Score
5.0
Spec-based adjustments
Based on Class A class averages
+1.5
Final Drivability & Handling
6.5
Living Space & Layout
5.5/10
Base Score
5.0
Spec-based adjustments
Based on Class A class averages
+0.5
Final Living Space & Layout
5.5
Comfort & Features
6.3/10
Base Score
5.0
Spec-based adjustments
Based on Class A class averages
+1.3
Final Comfort & Features
6.3
Storage Space
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Class A class averages
+0.0
Final Storage Space
5.0
Off-Grid & Campsites
5.8/10
Base Score
5.0
Spec-based adjustments
Based on Class A class averages
+0.8
Final Off-Grid & Campsites
5.8
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2017 Thor Motor Coach Palazzo 33-4, ensure your vehicle's rated tow capacity exceeds its GVWR of 26000 lbs. With a dry weight of lbs and hitch weight of lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Class A has a dry weight of lbs and a GVWR of 26000 lbs, giving a payload capacity of lbs for gear, water, and supplies.
The approximate dimensions are length 417 in., width 101 in., and height 142 in. Always confirm clearances for garages, storage, and campsites.
The Palazzo 33-4 includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many Palazzo 33-4 owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 26000 lbs and dry weight of lbs, the Palazzo 33-4 is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 8 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Class A.
The Palazzo 33-4 features body construction with sidewalls and 1 axle(s). Its GVWR of 26000 lbs ensures strength without excessive towing weight.
?? Tip: Always check your vehicle's specific towing capacity in the owner's manual. Consider payload and tongue weight too!
As an Amazon Associate, we may earn from qualifying purchases. Your price stays the same.
"Our mission at Mint RV is to help people make well-informed RV buying decisions, so they can escape the stress of everyday life, reconnect with family, and create unforgettable memories in the great outdoors"
