2017 Jayco Redhawk 29xk Specs
Know Before You Drive
Key specs for safe motorhome driving
⚠️ Height Alert: Over 11' tall. Watch for low bridges and overhangs!
Compact
<14k
Mid-Size
14-20k
Large
20-26k
XL
26k+
DRIVING QUICK FACTS
GVWR
14,500 lbs
License
Standard driver's license
Type
Class C
License Requirement
Standard driver's license
Standard
Check State
CDL May Apply
Essential Upgrades for the 2017 Jayco Redhawk 29xk
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 14500 lbs | - | - | - |
| Length | 384 in | Furrion Backup Camera | Shop Cameras | - |
| Width | 100 in | Clip On Mirrors | Shop Mirrors | - |
| Interior Height | 84 in | - | - | - |
| Towing Capacity | 7500 / 3402 lbs | - | - | - |
| Exterior Height | 137 in | Telescoping Ladder | Shop Ladders | - |
| Tongue Weight | 750 / 340.2 lbs | - | - | - |
Specs
Buy Now
More
GVWR
14500 lbs
Length
384 in
Width
100 in
Interior Height
84 in
Towing Capacity
7500 / 3402 lbs
Exterior Height
137 in
Tongue Weight
750 / 340.2 lbs
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Converter Amps | 60 | - | - | - |
| Shore Power | 30 Amps | - | - | - |
| Battery Type | 12V Lead-Acid | Renogy 100Ah LiFePO4 | RV Batteries | Top 5 |
| Solar Pre-Wired | Optional | - | - | - |
| Inverter | Optional | - | - | - |
Specs
Buy Now
More
Battery Converter Amps
60
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | - | - |
| Number Of Gray Water Holding Tanks | 1 | - | - | - |
| Number Of Black Water Holding Tanks | 1 | - | - | - |
| Fresh Water Tank Capacity | 32 gal | - | Fresh Water Tanks | - |
| Gray Water Tank Capacity | 40 gal | - | - | - |
| Black Water Tank Capacity | 32 gal | - | Back Water Tanks | - |
| Number Of Propane Tanks | 1 | - | - | - |
| Propane Tank Capacity | 42 lbs | - | Propane Tank Capacity | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Number Of Gray Water Holding Tanks
1
Number Of Black Water Holding Tanks
1
Fresh Water Tank Capacity
32 gal
Gray Water Tank Capacity
40 gal
Black Water Tank Capacity
32 gal
Number Of Propane Tanks
1
Propane Tank Capacity
42 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Rear Tire | LT225/75R 16E Full Spec | - | - | - |
| Rear Wheel Diameter | 16 | - | - | - |
| Front Tire | LT225/75R 16E Full Spec | - | - | - |
| Front Tire Speed Rating | E | - | - | - |
| Rear Tire Aspect Ratio | 75 | - | - | - |
| Wheelbase | 223 / 5664.2 in | - | - | - |
| Rear Brake Type | Hydraulic Disc | - | - | - |
| Front Wheel Diameter | 16 | - | - | - |
| Rear Tire Width | 225 | - | - | - |
| Front Brake Type | Hydraulic Disc | - | - | - |
| Front Tire Aspect Ratio | 75 | - | - | - |
| Rear Wheel Width | 6 in | - | - | - |
| Front Wheel Width | 6 in | - | - | - |
| Front Tire Width | 225 | - | - | - |
| Rear Tire Speed Rating | E | - | - | - |
| Wheels Composition | Steel | - | - | - |
Specs
Buy Now
More
Rear Tire
LT225/75R 16E Full Spec
Rear Wheel Diameter
16
Front Tire
LT225/75R 16E Full Spec
Front Tire Speed Rating
E
Rear Tire Aspect Ratio
75
Wheelbase
223 / 5664.2 in
Rear Brake Type
Hydraulic Disc
Front Wheel Diameter
16
Rear Tire Width
225
Front Brake Type
Hydraulic Disc
Front Tire Aspect Ratio
75
Rear Wheel Width
6 in
Front Wheel Width
6 in
Front Tire Width
225
Rear Tire Speed Rating
E
Wheels Composition
Steel
Heating & Cooling
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Air Conditioning Type | Automatic | Dometic 13.5K Air Conditioner | Shop All RV AC | - |
| Water Heater Tank Capacity | 6 g | RV Tank Water Heater | RV Water Heaters | - |
| Heater Type | Automatic | - | - | - |
| Water Heater Pump Power Mode | Electrical / Propane | - | - | - |
Specs
Buy Now
More
Air Conditioning Type
Automatic
Water Heater Tank Capacity
6 g
Heater Type
Automatic
Water Heater Pump Power Mode
Electrical / Propane
Heating & Cooling Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Queen Size Beds | 1 | Queen RV Mattress | Shop Mattresses | - |
| Number Of Bathrooms | 1 | - | - | - |
| Master Bedroom Door Style | Accordion | - | - | - |
| Master Bedroom Mirror Doors | No | - | - | - |
| Number Of Sofas | 1 | Tri-Fold Sofa | - | - |
| Full Size Master Bedroom Closet | No | - | - | - |
| Number Of Full Size Beds | 1 | - | - | - |
| Master Bedroom Location | Rear | - | - | - |
| Reclining Sofa | No | RV Loveseat Recliner Sofa | Shop Sofa | - |
| Living Area Location | Front | - | - | - |
| Number Of Convertible / Sofa Beds | 2 | - | - | - |
| Master Bedroom Flooring Type | Vinyl | - | - | - |
| Master Bedroom Shades / Curtains | Yes | - | - | - |
| Sofa Material | Vinyl | - | - | - |
Specs
Buy Now
More
Number Of Queen Size Beds
1
Number Of Bathrooms
1
Master Bedroom Door Style
Accordion
Master Bedroom Mirror Doors
No
Number Of Sofas
1
Full Size Master Bedroom Closet
No
Number Of Full Size Beds
1
Master Bedroom Location
Rear
Reclining Sofa
No
Living Area Location
Front
Number Of Convertible / Sofa Beds
2
Master Bedroom Flooring Type
Vinyl
Master Bedroom Shades / Curtains
Yes
Sofa Material
Vinyl
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Refrigerator Size | Mid-Size | - | - | - |
| Kitchen Table Configuration | U-shaped Dinette | - | - | - |
| Refrigerator Power Mode | Electric / Propane | - | - | - |
| Kitchen Location | Center | - | - | - |
| Number Of Oven Burners | 3 | - | - | - |
| Kitchen / Living Area Flooring Type | Vinyl | - | - | - |
Specs
Buy Now
More
Refrigerator Size
Mid-Size
Kitchen Table Configuration
U-shaped Dinette
Refrigerator Power Mode
Electric / Propane
Kitchen Location
Center
Number Of Oven Burners
3
Kitchen / Living Area Flooring Type
Vinyl
Bathroom
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Bathroom Location | Center | - | - | - |
| Bathroom Flooring Type | Vinyl | - | - | - |
| Toilet Type | Plastic | RV Toilet with Sprayer Attachment | Toilets | Top 5 |
Specs
Buy Now
More
Bathroom Location
Center
Bathroom Flooring Type
Vinyl
Toilet Type
Plastic
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Awning Length | 16 ft/m | Awning Fabric Replacement | All Awnings | - |
| Number of Awnings | 1 | Motorized RV Awning Set | Shop Awnings | - |
| Number Of Axles | 1 | - | - | - |
| Sidewall Construction | Fiberglass | - | - | - |
| Number Of Emergency Exits | 1 | - | - | - |
| Number of Doors | 1 | - | - | - |
| Door Type | Curtain | - | - | - |
| Body Material | Aluminum | - | - | - |
Specs
Buy Now
More
Awning Length
16 ft/m
Number of Awnings
1
Number Of Axles
1
Sidewall Construction
Fiberglass
Number Of Emergency Exits
1
Number of Doors
1
Door Type
Curtain
Body Material
Aluminum
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Screened Room | No | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Wallpaper | Yes | - | - | - |
| Power Adjustable Seat | No | - | - | - |
| Bunkhouse | No | - | - | - |
| Swivel Seats | No | - | - | - |
| Overdrive | Yes | - | - | - |
| Refrigerator | Standard | - | - | - |
| Sliding Glass Door | No | - | - | - |
| Water Heater Tank Bypass | Yes | - | - | - |
| Power Retractable Slideout | Yes | - | - | - |
| Satellite Prewiring | No | - | - | - |
| TV Antenna Prewiring | Yes | - | - | - |
| Phone Prewiring | No | - | - | - |
| Surround Sound | No | - | - | - |
| Metallic | No | - | - | - |
| Battery Power Converter | Yes | - | - | - |
| Seat Armrests | Yes | - | - | - |
| Interior Wood Finish | Yes | - | - | - |
| Washer / Dryer Prewiring | No | - | - | - |
| Power Retractable Awning | Yes | - | - | - |
| Cable Prewiring | Yes | - | - | - |
| Turbocharged | No | - | - | - |
| Overhead Fan | Yes | Overhead Fan | - | - |
| Satellite | No | - | - | - |
| Supercharged | No | - | - | - |
| Reclining Seats | Yes | - | - | - |
| Air Conditioning Prewiring | Yes | - | - | - |
Specs
Buy Now
More
Screened Room
No
Heat Prewiring
Yes
Wallpaper
Yes
Power Adjustable Seat
No
Bunkhouse
No
Swivel Seats
No
Overdrive
Yes
Refrigerator
Standard
Sliding Glass Door
No
Water Heater Tank Bypass
Yes
Power Retractable Slideout
Yes
Satellite Prewiring
No
TV Antenna Prewiring
Yes
Phone Prewiring
No
Surround Sound
No
Metallic
No
Battery Power Converter
Yes
Seat Armrests
Yes
Interior Wood Finish
Yes
Washer / Dryer Prewiring
No
Power Retractable Awning
Yes
Cable Prewiring
Yes
Turbocharged
No
Overhead Fan
Yes
Satellite
No
Supercharged
No
Reclining Seats
Yes
Air Conditioning Prewiring
Yes
Cabin Specs
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Seats | 2 | - | - | - |
| Seat Type | Bucket | - | - | - |
| Number Of Rows | 1 | - | - | - |
| Seat Specifications | Standard | - | - | - |
| Seat Material | Cloth | - | - | - |
Specs
Buy Now
More
Number Of Seats
2
Seat Type
Bucket
Number Of Rows
1
Seat Specifications
Standard
Seat Material
Cloth
Chasis
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Chassis Brand | Ford | - | - | - |
| Chassis Model | E450 | - | - | - |
Specs
Buy Now
More
Chassis Brand
Ford
Chassis Model
E450
Drivetrain
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Speeds | 6 | - | - | - |
| Transmission Type | Automatic | - | - | - |
| Driveline Type | 4X2 | - | - | - |
| Transmission Brand | TorqShift | - | - | - |
Specs
Buy Now
More
Number Of Speeds
6
Transmission Type
Automatic
Driveline Type
4X2
Transmission Brand
TorqShift
Engine
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Horsepower RPM | 4250 | - | - | - |
| Horsepower | 305 bhp | - | - | - |
| Cylinders | 10 | - | - | - |
| Engine Type | V10 | - | - | - |
| Torque | 569.4 Nm | - | - | - |
| Carburetion Type | Fuel Injected | - | - | - |
| Torque RPM | 3250 | - | - | - |
| Engine Brand Name | Triton® | - | - | - |
| Carburetion | Standard | - | - | - |
Specs
Buy Now
More
Horsepower RPM
4250
Horsepower
305 bhp
Cylinders
10
Engine Type
V10
Torque
569.4 Nm
Carburetion Type
Fuel Injected
Torque RPM
3250
Engine Brand Name
Triton®
Carburetion
Standard
Entertainment
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Discs | 1 | - | - | - |
| Speaker Location | Interior | RecPro Exterior Speakers | - | - |
| Number Of Televisions | 1 | Insignia LED HD Alexa TV | Shop RV TV's | - |
Specs
Buy Now
More
Number Of Discs
1
Speaker Location
Interior
Number Of Televisions
1
Entertainment Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Fuel & MPG
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Fuel Capacity | 55 / 208.2 gal/l | 5Gal Gas Can | - | - |
| Fuel Type | Gas | Fuel Treatment | - | - |
Specs
Buy Now
More
Fuel Capacity
55 / 208.2 gal/l
Fuel Type
Gas
Fuel & MPG Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Instrumentation
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Radios | 1 | - | - | - |
Specs
Buy Now
More
Number Of Radios
1
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Thor Industries | - | - | - |
| Year | 2017 | - | - | - |
| Make | Jayco | - | - | - |
| Display Name | Redhawk 29XK | - | - | - |
| Class | Class C | - | - | - |
| Max Sleeping Count | 8 | - | - | - |
| Number of Slideouts | 1 | - | - | - |
| Introduction Year | 2013 | - | - | - |
Specs
Buy Now
More
Parent Company
Thor Industries
Year
2017
Make
Jayco
Display Name
Redhawk 29XK
Class
Class C
Max Sleeping Count
8
Number of Slideouts
1
Introduction Year
2013
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this class c.
Drivability & Handling
6.3/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+1.3
Final Drivability & Handling
6.3
Living Space & Layout
5.8/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+0.8
Final Living Space & Layout
5.8
Comfort & Features
5.3/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+0.3
Final Comfort & Features
5.3
Storage Space
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
+0.0
Final Storage Space
5.0
Off-Grid & Campsites
4.8/10
Base Score
5.0
Spec-based adjustments
Based on Class C class averages
-0.2
Final Off-Grid & Campsites
4.8
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2017 Jayco Redhawk 29xk, ensure your vehicle's rated tow capacity exceeds its GVWR of 14500 lbs. With a dry weight of lbs and hitch weight of lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Class C has a dry weight of lbs and a GVWR of 14500 lbs, giving a payload capacity of lbs for gear, water, and supplies.
The approximate dimensions are length 384 in., width 100 in., and height 137 in. Always confirm clearances for garages, storage, and campsites.
The Redhawk 29xk includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many Redhawk 29xk owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 14500 lbs and dry weight of lbs, the Redhawk 29xk is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 8 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Class C.
The Redhawk 29xk features body construction with sidewalls and 1 axle(s). Its GVWR of 14500 lbs ensures strength without excessive towing weight.
?? Tip: Always check your vehicle's specific towing capacity in the owner's manual. Consider payload and tongue weight too!
As an Amazon Associate, we may earn from qualifying purchases. Your price stays the same.
"Our mission at Mint RV is to help people make well-informed RV buying decisions, so they can escape the stress of everyday life, reconnect with family, and create unforgettable memories in the great outdoors"
