2015 Coachmen RV Viking LS 1706 Specs
1
Can Your Vehicle Tow This?
Enter your vehicle to check manufacturer-rated limits
Loading your garage...
2
Get Your Real Numbers
Tow rating is one limit — payload is what overloads first
The full calculator factors in:
Tongue weight vs payload
Water tanks (50 gal = 417 lbs)
Propane (40 lbs full)
Passengers in truck
Gear, bikes, coolers, tools
Cargo weight distribution
Your truck's payload limit carries tongue weight, passengers, and everything in the bed — that's the number that overloads first. The calculator checks both tow and payload with real gear weights.
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 2098 lbs | - | ||
| Dry Weight | 1305 lbs | - | ||
| Hitch Weight | 120 lbs | - | - | - |
| Payload Capacity | 778 lbs | - | - | |
| Length | 203 in | - | ||
| Width | 85 in | - | ||
| Interior Height | 82 in | - |
Specs
Buy Now
More
GVWR
2098 lbs
Dry Weight
1305 lbs
Hitch Weight
120 lbs
Payload Capacity
778 lbs
Length
203 in
Width
85 in
Interior Height
82 in
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Converter Amps | 12 | - | ||
| Shore Power | 30 Amps | - | ||
| Battery Type | 12V Lead-Acid | Top 5 | ||
| Solar Pre-Wired | Optional | - | ||
| Inverter | Optional | - |
Specs
Buy Now
More
Battery Converter Amps
12
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | ||
| Fresh Water Tank Capacity | 16 gal | - | ||
| Number Of Propane Tanks | 1 | - | ||
| Propane Tank Capacity | 20 lbs | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Fresh Water Tank Capacity
16 gal
Number Of Propane Tanks
1
Propane Tank Capacity
20 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Front Brake Type | Not Applicable | - | - | - |
| Rear Brake Type | Electric Drum | - | ||
| Rear Tire | 5.30 x 12 Full Spec | - | - | - |
| Rear Wheel Diameter | 12 | - | - | - |
| Wheels Composition | Steel | - | - | - |
Specs
Buy Now
More
Front Brake Type
Not Applicable
Rear Brake Type
Electric Drum
Rear Tire
5.30 x 12 Full Spec
Rear Wheel Diameter
12
Wheels Composition
Steel
Tires & Wheels Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Living Area Location | Center | - | - | - |
| Number Of Convertible / Sofa Beds | 1 | - | - | - |
| Number Of Double Beds | 2 | - | - | - |
Specs
Buy Now
More
Living Area Location
Center
Number Of Convertible / Sofa Beds
1
Number Of Double Beds
2
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Kitchen / Living Area Flooring Type | Vinyl | - | - | - |
| Kitchen Location | Center | - | - | - |
| Kitchen Table Configuration | Bench Seats | - | - | - |
| Number Of Oven Burners | 2 | - | - | - |
Specs
Buy Now
More
Kitchen / Living Area Flooring Type
Vinyl
Kitchen Location
Center
Kitchen Table Configuration
Bench Seats
Number Of Oven Burners
2
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Leveling Jack Type | Front Manual / Rear Manual | - | - | - |
| Expandable Bunk Material | Soft Shell | - | - | - |
| Number Of Axles | 1 | - | - | - |
| Sidewall Construction | Tent Fabric | - | - | - |
| Number of Doors | 1 | - | ||
| Body Material | Aluminum | - | - | - |
Specs
Buy Now
More
Leveling Jack Type
Front Manual / Rear Manual
Expandable Bunk Material
Soft Shell
Number Of Axles
1
Sidewall Construction
Tent Fabric
Number of Doors
1
Body Material
Aluminum
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Air Conditioning Prewiring | No | - | ||
| Battery Power Converter | Yes | - | - | - |
| Bunkhouse | No | - | - | - |
| Cable Prewiring | No | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Interior Wood Finish | No | - | - | - |
| Phone Prewiring | No | - | - | - |
| Refrigerator | Optional | - | - | - |
| Satellite Prewiring | No | - | - | - |
| Sliding Glass Door | No | - | - | - |
| TV Antenna Prewiring | No | - | - | - |
| Wallpaper | No | - | - | - |
| Washer / Dryer Prewiring | No | - | - | - |
Specs
Buy Now
More
Air Conditioning Prewiring
No
Battery Power Converter
Yes
Bunkhouse
No
Cable Prewiring
No
Heat Prewiring
Yes
Interior Wood Finish
No
Phone Prewiring
No
Refrigerator
Optional
Satellite Prewiring
No
Sliding Glass Door
No
TV Antenna Prewiring
No
Wallpaper
No
Washer / Dryer Prewiring
No
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Forest River | - | - | - |
| Year | 2015 | - | - | - |
| Make | Coachmen | - | - | - |
| Display Name | Viking LS 1706 | - | - | - |
| Class | Expandable Trailer | - | - | - |
| Max Sleeping Count | 6 | - | - | - |
| Introduction Year | 2012 | - | - | - |
Specs
Buy Now
More
Parent Company
Forest River
Year
2015
Make
Coachmen
Display Name
Viking LS 1706
Class
Expandable Trailer
Max Sleeping Count
6
Introduction Year
2012
Essential Upgrades for the 2015 Coachmen RV Viking LS 1706
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this expandable trailer.
Tow-Ready Score
8.8/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
+3.8
Final Tow-Ready Score
8.8
Living Space & Layout
4.0/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
-1.0
Final Living Space & Layout
4.0
Comfort & Features
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
+0.0
Final Comfort & Features
5.0
Storage Space
6.5/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
+1.5
Final Storage Space
6.5
Off-Grid & Campsites
5.5/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
+0.5
Final Off-Grid & Campsites
5.5
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2015 Coachmen RV Viking LS 1706, ensure your vehicle's rated tow capacity exceeds its GVWR of 2098 lbs. With a dry weight of 1305 lbs and hitch weight of 120 lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Expandable Trailer has a dry weight of 1305 lbs and a GVWR of 2098 lbs, giving a payload capacity of 778 lbs for gear, water, and supplies.
The approximate dimensions are length 203 in., width 85 in., and height in. Always confirm clearances for garages, storage, and campsites.
The Viking LS 1706 includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many Viking LS 1706 owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 2098 lbs and dry weight of 1305 lbs, the Viking LS 1706 is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 6 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Expandable Trailer.
The Viking LS 1706 features body construction with sidewalls and 1 axle(s). Its GVWR of 2098 lbs ensures strength without excessive towing weight.
?? Tip: Always check your vehicle's specific towing capacity in the owner's manual. Consider payload and tongue weight too!
