2013 Livin Lite Camp Lite 11fdb Specs
1
Can Your Vehicle Tow This?
Enter your vehicle to check manufacturer-rated limits
Loading your garage...
2
Get Your Real Numbers
Tow rating is one limit — payload is what overloads first
The full calculator factors in:
Tongue weight vs payload
Water tanks (50 gal = 417 lbs)
Propane (40 lbs full)
Passengers in truck
Gear, bikes, coolers, tools
Cargo weight distribution
Your truck's payload limit carries tongue weight, passengers, and everything in the bed — that's the number that overloads first. The calculator checks both tow and payload with real gear weights.
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 2700 lbs | - | ||
| Dry Weight | 1995 lbs | - | ||
| Hitch Weight | 180 lbs | - | ||
| Payload Capacity | 705 lbs | - | ||
| Length | 174 in | - | ||
| Width | 84 in | - | ||
| Exterior Height | 114 in | - |
Specs
Buy Now
More
GVWR
2700 lbs
Dry Weight
1995 lbs
Hitch Weight
180 lbs
Payload Capacity
705 lbs
Length
174 in
Width
84 in
Exterior Height
114 in
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Shore Power | 30 Amps | - | ||
| Battery Type | 12V Lead-Acid | Top 5 | ||
| Solar Pre-Wired | Optional | - | ||
| Inverter | Optional | - |
Specs
Buy Now
More
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | ||
| Number Of Gray Water Holding Tanks | 1 | - | ||
| Number Of Black Water Holding Tanks | 1 | - | ||
| Fresh Water Tank Capacity | 20 gal | - | ||
| Gray Water Tank Capacity | 28 gal | - | ||
| Black Water Tank Capacity | 14 gal | - | - | |
| Number Of Propane Tanks | 1 | - | ||
| Propane Tank Capacity | 20 lbs | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Number Of Gray Water Holding Tanks
1
Number Of Black Water Holding Tanks
1
Fresh Water Tank Capacity
20 gal
Gray Water Tank Capacity
28 gal
Black Water Tank Capacity
14 gal
Number Of Propane Tanks
1
Propane Tank Capacity
20 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Front Brake Type | Not Applicable | - | - | - |
| Rear Brake Type | Electric Drum | - | ||
| Rear Tire | 13 - Inch Tires Full Spec | - | - | - |
| Rear Wheel Diameter | 13 | - | - | - |
| Spare Tire Location | Exterior Mounted | - | ||
| Wheels Composition | Aluminum | - | - | - |
Specs
Buy Now
More
Front Brake Type
Not Applicable
Rear Brake Type
Electric Drum
Rear Tire
13 - Inch Tires Full Spec
Rear Wheel Diameter
13
Spare Tire Location
Exterior Mounted
Wheels Composition
Aluminum
Tires & Wheels Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Heating & Cooling
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Heater Type | Automatic | - | ||
| Water Heater Pump Power Mode | Propane | - | - | - |
Specs
Buy Now
More
Heater Type
Automatic
Water Heater Pump Power Mode
Propane
Heating & Cooling Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Living Area Location | Front | - | - | - |
| Number Of Convertible / Sofa Beds | 1 | - | - | - |
Specs
Buy Now
More
Living Area Location
Front
Number Of Convertible / Sofa Beds
1
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Kitchen / Living Area Flooring Type | Aluminum | - | - | - |
| Kitchen Location | Center | - | - | - |
| Kitchen Table Configuration | Bench Seats | - | - | - |
| Number Of Oven Burners | 2 | - | - | - |
| Refrigerator Power Mode | Electric / Propane | - | - | - |
| Refrigerator Size | Compact | - | - | - |
Specs
Buy Now
More
Kitchen / Living Area Flooring Type
Aluminum
Kitchen Location
Center
Kitchen Table Configuration
Bench Seats
Number Of Oven Burners
2
Refrigerator Power Mode
Electric / Propane
Refrigerator Size
Compact
Bathroom
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Bathroom Flooring Type | Aluminum | - | - | - |
| Bathroom Location | Rear | - | - | - |
| Number Of Bathrooms | 1 | - | - | - |
| Toilet Type | Porcelain | Top 5 |
Specs
Buy Now
More
Bathroom Flooring Type
Aluminum
Bathroom Location
Rear
Number Of Bathrooms
1
Toilet Type
Porcelain
Bathroom Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Leveling Jack Type | Front Manual / Rear Manual | - | - | - |
| Number Of Axles | 1 | - | - | - |
| Sidewall Construction | Aluminum | - | - | - |
| Number of Doors | 1 | - | ||
| Body Material | Aluminum | - | - | - |
Specs
Buy Now
More
Leveling Jack Type
Front Manual / Rear Manual
Number Of Axles
1
Sidewall Construction
Aluminum
Number of Doors
1
Body Material
Aluminum
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Power Converter | Yes | - | - | - |
| Bunkhouse | No | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Interior Wood Finish | Yes | - | - | - |
| Metallic | No | - | - | - |
| Overhead Fan | No | - | - | |
| Phone Prewiring | No | - | - | - |
| Refrigerator | Standard | - | - | - |
| Satellite Prewiring | No | - | - | - |
| Sliding Glass Door | No | - | - | - |
| TV Antenna Prewiring | Yes | - | - | - |
| Wallpaper | Yes | - | - | - |
| Washer / Dryer Prewiring | No | - | - | - |
| Water Heater Tank Bypass | No | - | - | - |
Specs
Buy Now
More
Battery Power Converter
Yes
Bunkhouse
No
Heat Prewiring
Yes
Interior Wood Finish
Yes
Metallic
No
Overhead Fan
No
Phone Prewiring
No
Refrigerator
Standard
Satellite Prewiring
No
Sliding Glass Door
No
TV Antenna Prewiring
Yes
Wallpaper
Yes
Washer / Dryer Prewiring
No
Water Heater Tank Bypass
No
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Livin Lite Recreational Vehicles | - | - | - |
| Year | 2013 | - | - | - |
| Make | Livin` Lite | - | - | - |
| Display Name | Camp Lite 11FDB | - | - | - |
| Class | Travel Trailer | - | - | - |
| Max Sleeping Count | 3 | - | - | - |
Specs
Buy Now
More
Parent Company
Livin Lite Recreational Vehicles
Year
2013
Make
Livin` Lite
Display Name
Camp Lite 11FDB
Class
Travel Trailer
Max Sleeping Count
3
Essential Upgrades for the 2013 Livin Lite Camp Lite 11fdb
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this travel trailer.
Tow-Ready Score
9.8/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+4.8
Final Tow-Ready Score
9.8
Living Space & Layout
6.0/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+1.0
Final Living Space & Layout
6.0
Comfort & Features
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+0.0
Final Comfort & Features
5.0
Storage Space
6.0/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+1.0
Final Storage Space
6.0
Off-Grid & Campsites
6.0/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+1.0
Final Off-Grid & Campsites
6.0
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2013 Livin Lite Camp Lite 11fdb, ensure your vehicle's rated tow capacity exceeds its GVWR of 2700 lbs. With a dry weight of 1995 lbs and hitch weight of 180 lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Travel Trailer has a dry weight of 1995 lbs and a GVWR of 2700 lbs, giving a payload capacity of 705 lbs for gear, water, and supplies.
The approximate dimensions are length 174 in., width 84 in., and height 114 in. Always confirm clearances for garages, storage, and campsites.
The Camp Lite 11fdb includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many Camp Lite 11fdb owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 2700 lbs and dry weight of 1995 lbs, the Camp Lite 11fdb is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 3 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Travel Trailer.
The Camp Lite 11fdb features body construction with sidewalls and 1 axle(s). Its GVWR of 2700 lbs ensures strength without excessive towing weight.
?? Tip: Always check your vehicle's specific towing capacity in the owner's manual. Consider payload and tongue weight too!
