2013 Coachmen RV Viking Legend 2485-sst Specs
1
Can Your Vehicle Tow This?
Enter your vehicle to check manufacturer-rated limits
Loading your garage...
2
Get Your Real Numbers
Tow rating is one limit — payload is what overloads first
The full calculator factors in:
Tongue weight vs payload
Water tanks (50 gal = 417 lbs)
Propane (40 lbs full)
Passengers in truck
Gear, bikes, coolers, tools
Cargo weight distribution
Your truck's payload limit carries tongue weight, passengers, and everything in the bed — that's the number that overloads first. The calculator checks both tow and payload with real gear weights.
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 3502 lbs | - | ||
| Dry Weight | 2702 lbs | - | ||
| Hitch Weight | 282 lbs | - | - | - |
| Payload Capacity | 800 lbs | - | - | |
| Length | 293 in | - | ||
| Width | 85 in | - | ||
| Interior Height | 82 in | - |
Specs
Buy Now
More
GVWR
3502 lbs
Dry Weight
2702 lbs
Hitch Weight
282 lbs
Payload Capacity
800 lbs
Length
293 in
Width
85 in
Interior Height
82 in
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Converter Amps | 25 | - | ||
| Shore Power | 30 Amps | - | ||
| Battery Type | 12V Lead-Acid | Top 5 | ||
| Solar Pre-Wired | Optional | - | ||
| Inverter | Optional | - |
Specs
Buy Now
More
Battery Converter Amps
25
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | ||
| Fresh Water Tank Capacity | 23 gal | - | ||
| Number Of Propane Tanks | 1 | - | ||
| Propane Tank Capacity | 20 lbs | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Fresh Water Tank Capacity
23 gal
Number Of Propane Tanks
1
Propane Tank Capacity
20 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Front Brake Type | Not Applicable | - | - | - |
| Rear Brake Type | Hydraulic Drum | - | - | - |
| Rear Tire | 175/80R13 Full Spec | - | - | - |
| Rear Tire Aspect Ratio | 80 | - | - | - |
| Rear Tire Width | 175 | - | - | - |
| Rear Wheel Diameter | 13 | - | - | - |
| Wheels Composition | Aluminum | - | - | - |
Specs
Buy Now
More
Front Brake Type
Not Applicable
Rear Brake Type
Hydraulic Drum
Rear Tire
175/80R13 Full Spec
Rear Tire Aspect Ratio
80
Rear Tire Width
175
Rear Wheel Diameter
13
Wheels Composition
Aluminum
Tires & Wheels Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Heating & Cooling
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Water Heater Tank Capacity | 6 g | - |
Specs
Buy Now
More
Water Heater Tank Capacity
6 g
Heating & Cooling Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Living Area Location | Center | - | - | - |
| Number Of Convertible / Sofa Beds | 2 | - | - | - |
| Number Of King Size Beds | 2 | - | - | - |
| Number Of Sofas | 1 | - | - | |
| Sofa Material | Cloth | - | - | - |
Specs
Buy Now
More
Living Area Location
Center
Number Of Convertible / Sofa Beds
2
Number Of King Size Beds
2
Number Of Sofas
1
Sofa Material
Cloth
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Kitchen / Living Area Flooring Type | Vinyl | - | - | - |
| Kitchen Location | Center | - | - | - |
| Kitchen Table Configuration | Bench Seats | - | - | - |
| Number Of Oven Burners | 3 | - | - | - |
Specs
Buy Now
More
Kitchen / Living Area Flooring Type
Vinyl
Kitchen Location
Center
Kitchen Table Configuration
Bench Seats
Number Of Oven Burners
3
Bathroom
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Toilet Type | Cassette (With Curtain / Walls) | Top 5 |
Specs
Buy Now
More
Toilet Type
Cassette (With Curtain / Walls)
Bathroom Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Leveling Jack Type | Front Manual / Rear Manual | - | - | - |
| Expandable Bunk Material | Soft Shell | - | - | - |
| Number Of Axles | 1 | - | - | - |
| Sidewall Construction | Tent Fabric | - | - | - |
| Number of Doors | 1 | - | ||
| Door Type | Curtain | - | ||
| Body Material | Fiberglass | - | - | - |
Specs
Buy Now
More
Leveling Jack Type
Front Manual / Rear Manual
Expandable Bunk Material
Soft Shell
Number Of Axles
1
Sidewall Construction
Tent Fabric
Number of Doors
1
Door Type
Curtain
Body Material
Fiberglass
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Power Converter | Yes | - | - | - |
| Bunkhouse | No | - | - | - |
| Cable Prewiring | No | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Phone Prewiring | No | - | - | - |
| Power Retractable Slideout | No | - | - | - |
| Refrigerator | Optional | - | - | - |
| Satellite | No | - | - | - |
| Satellite Prewiring | No | - | - | - |
| Sliding Glass Door | No | - | - | - |
| Surround Sound | No | - | - | - |
| TV Antenna Prewiring | No | - | - | - |
| Washer / Dryer Prewiring | No | - | - | - |
Specs
Buy Now
More
Battery Power Converter
Yes
Bunkhouse
No
Cable Prewiring
No
Heat Prewiring
Yes
Phone Prewiring
No
Power Retractable Slideout
No
Refrigerator
Optional
Satellite
No
Satellite Prewiring
No
Sliding Glass Door
No
Surround Sound
No
TV Antenna Prewiring
No
Washer / Dryer Prewiring
No
Entertainment
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Discs | 1 | - | - | - |
| Speaker Location | Exterior | - | - |
Specs
Buy Now
More
Number Of Discs
1
Speaker Location
Exterior
Entertainment Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Instrumentation
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Radios | 1 | - | - | - |
Specs
Buy Now
More
Number Of Radios
1
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Forest River | - | - | - |
| Year | 2013 | - | - | - |
| Make | Coachmen | - | - | - |
| Display Name | Viking Legend Series 2485 SST | - | - | - |
| Class | Expandable Trailer | - | - | - |
| Max Sleeping Count | 7 | - | - | - |
| Number of Slideouts | 1 | - | - | - |
| Introduction Year | 2012 | - | - | - |
Specs
Buy Now
More
Parent Company
Forest River
Year
2013
Make
Coachmen
Display Name
Viking Legend Series 2485 SST
Class
Expandable Trailer
Max Sleeping Count
7
Number of Slideouts
1
Introduction Year
2012
Essential Upgrades for the 2013 Coachmen RV Viking Legend 2485-sst
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this expandable trailer.
Tow-Ready Score
5.5/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
+0.5
Final Tow-Ready Score
5.5
Living Space & Layout
6.5/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
+1.5
Final Living Space & Layout
6.5
Comfort & Features
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
+0.0
Final Comfort & Features
5.0
Storage Space
4.5/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
-0.5
Final Storage Space
4.5
Off-Grid & Campsites
6.0/10
Base Score
5.0
Spec-based adjustments
Based on Expandable Trailer class averages
+1.0
Final Off-Grid & Campsites
6.0
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2013 Coachmen RV Viking Legend 2485-sst, ensure your vehicle's rated tow capacity exceeds its GVWR of 3502 lbs. With a dry weight of 2702 lbs and hitch weight of 282 lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Expandable Trailer has a dry weight of 2702 lbs and a GVWR of 3502 lbs, giving a payload capacity of 800 lbs for gear, water, and supplies.
The approximate dimensions are length 293 in., width 85 in., and height in. Always confirm clearances for garages, storage, and campsites.
The Viking Legend 2485-sst includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many Viking Legend 2485-sst owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 3502 lbs and dry weight of 2702 lbs, the Viking Legend 2485-sst is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 7 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Expandable Trailer.
The Viking Legend 2485-sst features body construction with sidewalls and 1 axle(s). Its GVWR of 3502 lbs ensures strength without excessive towing weight.
