2010 Skyline Weekender Limited 230 Specs
Can Your Vehicle Tow This?
Interactive towing compatibility checker
Select Your Tow Vehicle
RECOMMENDED TOW VEHICLES
Ford F-150
Up to 14,000 lbs
Ram 1500
Up to 12,750 lbs
Silverado 1500
Up to 13,300 lbs
Toyota Tundra
Up to 12,000 lbs
Safe Towing Capacity
80%
Under capacity
Safe zone
Max rating
Essential Upgrades for the 2010 Skyline Weekender Limited 230
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 6200 lbs | Class 4 Receiver | Shop Receivers | - |
| Dry Weight | 3875 lbs | CURT WD Hitch & Sway Controller | Shop Weight Distributing Hitches | - |
| Hitch Weight | 600 lbs | ReeseTrailer Hitch | Shop Hitches | - |
| Payload Capacity | 2175 lbs | Coil SumoSprings | Shop Suspension Kits | - |
| Length | 335 in | Furrion Backup Camera | Shop Cameras | - |
| Width | 96 in | Clip On Mirrors | Shop Mirrors | - |
| Interior Height | 76 in | - | - | - |
| Exterior Height | 122 in | Telescoping Ladder | Shop Ladders | - |
Specs
Buy Now
More
GVWR
6200 lbs
Dry Weight
3875 lbs
Hitch Weight
600 lbs
Payload Capacity
2175 lbs
Length
335 in
Width
96 in
Interior Height
76 in
Exterior Height
122 in
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Converter Amps | 55 | - | - | - |
| Shore Power | 30 Amps | - | - | - |
| Battery Type | 12V Lead-Acid | Renogy 100Ah LiFePO4 | RV Batteries | Top 5 |
| Solar Pre-Wired | Optional | - | - | - |
| Inverter | Optional | - | - | - |
Specs
Buy Now
More
Battery Converter Amps
55
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | - | - |
| Number Of Gray Water Holding Tanks | 1 | - | - | - |
| Number Of Black Water Holding Tanks | 1 | - | - | - |
| Fresh Water Tank Capacity | 36 gal | - | Fresh Water Tanks | - |
| Gray Water Tank Capacity | 31 gal | - | - | - |
| Black Water Tank Capacity | 31 gal | - | Back Water Tanks | - |
| Number Of Propane Tanks | 2 | - | - | - |
| Propane Tank Capacity | 40 lbs | - | Propane Tank Capacity | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Number Of Gray Water Holding Tanks
1
Number Of Black Water Holding Tanks
1
Fresh Water Tank Capacity
36 gal
Gray Water Tank Capacity
31 gal
Black Water Tank Capacity
31 gal
Number Of Propane Tanks
2
Propane Tank Capacity
40 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Rear Tire | ST205/75C R14 Full Spec | - | - | - |
| Rear Tire Speed Rating | C | - | - | - |
| Rear Brake Type | Electric Drum | - | - | - |
| Rear Wheel Diameter | 14 | - | - | - |
| Rear Tire Aspect Ratio | 75 | - | - | - |
| Wheels Composition | Steel | - | - | - |
| Rear Tire Width | 205 | - | - | - |
Specs
Buy Now
More
Rear Tire
ST205/75C R14 Full Spec
Rear Tire Speed Rating
C
Rear Brake Type
Electric Drum
Rear Wheel Diameter
14
Rear Tire Aspect Ratio
75
Wheels Composition
Steel
Rear Tire Width
205
Heating & Cooling
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Water Heater Tank Capacity | 6 g | RV Tank Water Heater | RV Water Heaters | - |
| Heater Type | Automatic | - | - | - |
| Water Heater Pump Power Mode | Propane | - | - | - |
Specs
Buy Now
More
Water Heater Tank Capacity
6 g
Heater Type
Automatic
Water Heater Pump Power Mode
Propane
Heating & Cooling Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Sofas | 1 | Tri-Fold Sofa | - | - |
| Number Of Convertible / Sofa Beds | 2 | - | - | - |
| Master Bedroom Flooring Type | Vinyl | - | - | - |
| Master Bedroom Shades / Curtains | Yes | - | - | - |
| Living Area Location | Center | - | - | - |
| Number Of Bathrooms | 1 | - | - | - |
| Master Bedroom Door Style | Curtain | - | - | - |
| Sofa Material | Cloth | - | - | - |
| Number Of Queen Size Beds | 1 | Queen RV Mattress | Shop Mattresses | - |
| Master Bedroom Mirror Doors | No | - | - | - |
| Master Bedroom Location | Front | - | - | - |
| Full Size Master Bedroom Closet | No | - | - | - |
Specs
Buy Now
More
Number Of Sofas
1
Number Of Convertible / Sofa Beds
2
Master Bedroom Flooring Type
Vinyl
Master Bedroom Shades / Curtains
Yes
Living Area Location
Center
Number Of Bathrooms
1
Master Bedroom Door Style
Curtain
Sofa Material
Cloth
Number Of Queen Size Beds
1
Master Bedroom Mirror Doors
No
Master Bedroom Location
Front
Full Size Master Bedroom Closet
No
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Kitchen Table Configuration | Bench Seats | - | - | - |
| Refrigerator Power Mode | Electric / Propane | - | - | - |
| Kitchen Location | Center | - | - | - |
| Number Of Oven Burners | 3 | - | - | - |
| Kitchen / Living Area Flooring Type | Vinyl | - | - | - |
| Refrigerator Size | Mid-Size | - | - | - |
Specs
Buy Now
More
Kitchen Table Configuration
Bench Seats
Refrigerator Power Mode
Electric / Propane
Kitchen Location
Center
Number Of Oven Burners
3
Kitchen / Living Area Flooring Type
Vinyl
Refrigerator Size
Mid-Size
Bathroom
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Toilet Type | Plastic | RV Toilet with Sprayer Attachment | Toilets | Top 5 |
| Bathroom Location | Rear | - | - | - |
| Bathroom Flooring Type | Vinyl | - | - | - |
Specs
Buy Now
More
Toilet Type
Plastic
Bathroom Location
Rear
Bathroom Flooring Type
Vinyl
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Axles | 2 | - | - | - |
| Sidewall Construction | Sheet Metal | - | - | - |
| Number of Doors | 1 | - | - | - |
| Body Material | Wood | - | - | - |
Specs
Buy Now
More
Number Of Axles
2
Sidewall Construction
Sheet Metal
Number of Doors
1
Body Material
Wood
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Water Heater Tank Bypass | Yes | - | - | - |
| Air Conditioning Prewiring | Yes | - | - | - |
| Overhead Fan | Yes | Overhead Fan | - | - |
| TV Antenna Prewiring | Yes | - | - | - |
| Interior Wood Finish | Yes | - | - | - |
| Refrigerator | Standard | - | - | - |
| Cable Prewiring | Yes | - | - | - |
| Washer / Dryer Prewiring | No | - | - | - |
| Sliding Glass Door | No | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Battery Power Converter | Yes | - | - | - |
| Phone Prewiring | No | - | - | - |
| Wallpaper | Yes | - | - | - |
| Satellite Prewiring | No | - | - | - |
Specs
Buy Now
More
Water Heater Tank Bypass
Yes
Air Conditioning Prewiring
Yes
Overhead Fan
Yes
TV Antenna Prewiring
Yes
Interior Wood Finish
Yes
Refrigerator
Standard
Cable Prewiring
Yes
Washer / Dryer Prewiring
No
Sliding Glass Door
No
Heat Prewiring
Yes
Battery Power Converter
Yes
Phone Prewiring
No
Wallpaper
Yes
Satellite Prewiring
No
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Skyline Corporation | - | - | - |
| Year | 2010 | - | - | - |
| Make | Skyline | - | - | - |
| Display Name | Weekender Limited 230 | - | - | - |
| Class | Travel Trailer | - | - | - |
| Max Sleeping Count | 6 | - | - | - |
Specs
Buy Now
More
Parent Company
Skyline Corporation
Year
2010
Make
Skyline
Display Name
Weekender Limited 230
Class
Travel Trailer
Max Sleeping Count
6
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this travel trailer.
Tow-Ready Score
6.8/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+1.8
Final Tow-Ready Score
6.8
Living Space & Layout
6.0/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+1.0
Final Living Space & Layout
6.0
Comfort & Features
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+0.0
Final Comfort & Features
5.0
Storage Space
6.5/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+1.5
Final Storage Space
6.5
Off-Grid & Campsites
5.8/10
Base Score
5.0
Spec-based adjustments
Based on Travel Trailer class averages
+0.8
Final Off-Grid & Campsites
5.8
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2010 Skyline Weekender Limited 230, ensure your vehicle's rated tow capacity exceeds its GVWR of 6200 lbs. With a dry weight of 3875 lbs and hitch weight of 600 lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Travel Trailer has a dry weight of 3875 lbs and a GVWR of 6200 lbs, giving a payload capacity of 2175 lbs for gear, water, and supplies.
The approximate dimensions are length 335 in., width 96 in., and height 122 in. Always confirm clearances for garages, storage, and campsites.
The Weekender Limited 230 includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many Weekender Limited 230 owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 6200 lbs and dry weight of 3875 lbs, the Weekender Limited 230 is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 6 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Travel Trailer.
The Weekender Limited 230 features body construction with sidewalls and 2 axle(s). Its GVWR of 6200 lbs ensures strength without excessive towing weight.
