2009 Skyline Layton Way-Lite Ramp Trailer 199 Specs
1
Can Your Vehicle Tow This?
Enter your vehicle to check manufacturer-rated limits
Loading your garage...
2
Get Your Real Numbers
Tow rating is one limit — payload is what overloads first
The full calculator factors in:
Tongue weight vs payload
Water tanks (50 gal = 417 lbs)
Propane (40 lbs full)
Passengers in truck
Gear, bikes, coolers, tools
Cargo weight distribution
Your truck's payload limit carries tongue weight, passengers, and everything in the bed — that's the number that overloads first. The calculator checks both tow and payload with real gear weights.
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 7750 lbs | - | ||
| Dry Weight | 4625 lbs | - | ||
| Hitch Weight | 700 lbs | - | - | - |
| Payload Capacity | 2950 lbs | - | ||
| Length | 286 in | - | ||
| Width | 96 in | - | ||
| Exterior Height | 138 in | - | ||
| Interior Height | 94 in | - |
Specs
Buy Now
More
GVWR
7750 lbs
Dry Weight
4625 lbs
Hitch Weight
700 lbs
Payload Capacity
2950 lbs
Length
286 in
Width
96 in
Exterior Height
138 in
Interior Height
94 in
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Converter Amps | 55 | - | ||
| Shore Power | 30 Amps | - | ||
| Battery Type | 12V Lead-Acid | Top 5 | ||
| Solar Pre-Wired | Optional | - | ||
| Inverter | Optional | - |
Specs
Buy Now
More
Battery Converter Amps
55
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | ||
| Number Of Gray Water Holding Tanks | 1 | - | ||
| Number Of Black Water Holding Tanks | 1 | - | ||
| Fresh Water Tank Capacity | 62 gal | - | - | |
| Gray Water Tank Capacity | 37 gal | - | ||
| Black Water Tank Capacity | 40 gal | - | - | |
| Number Of Propane Tanks | 2 | - | ||
| Propane Tank Capacity | 40 lbs | - | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Number Of Gray Water Holding Tanks
1
Number Of Black Water Holding Tanks
1
Fresh Water Tank Capacity
62 gal
Gray Water Tank Capacity
37 gal
Black Water Tank Capacity
40 gal
Number Of Propane Tanks
2
Propane Tank Capacity
40 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Rear Brake Type | Electric Drum | - | ||
| Rear Tire | ST205/75C R15 Full Spec | - | - | - |
| Rear Tire Aspect Ratio | 75 | - | - | - |
| Rear Tire Speed Rating | C | - | - | - |
| Rear Tire Width | 205 | - | - | - |
| Rear Wheel Diameter | 15 | - | ||
| Wheels Composition | Steel | - | - | - |
Specs
Buy Now
More
Rear Brake Type
Electric Drum
Rear Tire
ST205/75C R15 Full Spec
Rear Tire Aspect Ratio
75
Rear Tire Speed Rating
C
Rear Tire Width
205
Rear Wheel Diameter
15
Wheels Composition
Steel
Tires & Wheels Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Heating & Cooling
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Water Heater Tank Capacity | 6 g | - | ||
| Heater Type | Automatic | - | ||
| Water Heater Pump Power Mode | Propane | - | - | - |
Specs
Buy Now
More
Water Heater Tank Capacity
6 g
Heater Type
Automatic
Water Heater Pump Power Mode
Propane
Heating & Cooling Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Living Area Location | Center | - | - | - |
| Number Of Convertible / Sofa Beds | 2 | - | - | - |
| Number Of Sofas | 2 | - | - | |
| Sofa Material | Cloth | - | - | - |
Specs
Buy Now
More
Living Area Location
Center
Number Of Convertible / Sofa Beds
2
Number Of Sofas
2
Sofa Material
Cloth
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Kitchen / Living Area Flooring Type | Vinyl | - | - | - |
| Kitchen Location | Front | - | - | - |
| Kitchen Table Configuration | Bench Seats | - | - | - |
| Number Of Oven Burners | 3 | - | - | - |
| Refrigerator Power Mode | Electric / Propane | - | - | - |
| Refrigerator Size | Mid-Size | - | - | - |
Specs
Buy Now
More
Kitchen / Living Area Flooring Type
Vinyl
Kitchen Location
Front
Kitchen Table Configuration
Bench Seats
Number Of Oven Burners
3
Refrigerator Power Mode
Electric / Propane
Refrigerator Size
Mid-Size
Bathroom
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Bathroom Flooring Type | Vinyl | - | - | - |
| Bathroom Location | Front | - | - | - |
| Number Of Bathrooms | 1 | - | - | - |
| Toilet Type | Plastic | Top 5 |
Specs
Buy Now
More
Bathroom Flooring Type
Vinyl
Bathroom Location
Front
Number Of Bathrooms
1
Toilet Type
Plastic
Bathroom Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Axles | 2 | - | - | - |
| Sidewall Construction | Sheet Metal | - | - | - |
| Number of Doors | 1 | - | ||
| Body Material | Wood | - | - | - |
Specs
Buy Now
More
Number Of Axles
2
Sidewall Construction
Sheet Metal
Number of Doors
1
Body Material
Wood
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Air Conditioning Prewiring | Yes | - | ||
| Battery Power Converter | Yes | - | - | - |
| Cable Prewiring | Yes | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Interior Wood Finish | Yes | - | - | - |
| Metallic | No | - | - | - |
| Overhead Fan | Yes | - | - | |
| Phone Prewiring | No | - | - | - |
| Refrigerator | Standard | - | - | - |
| Satellite Prewiring | Yes | - | - | - |
| Sliding Glass Door | No | - | - | - |
| TV Antenna Prewiring | Yes | - | - | - |
| Wallpaper | Yes | - | - | - |
| Washer / Dryer Prewiring | No | - | - | - |
Specs
Buy Now
More
Air Conditioning Prewiring
Yes
Battery Power Converter
Yes
Cable Prewiring
Yes
Heat Prewiring
Yes
Interior Wood Finish
Yes
Metallic
No
Overhead Fan
Yes
Phone Prewiring
No
Refrigerator
Standard
Satellite Prewiring
Yes
Sliding Glass Door
No
TV Antenna Prewiring
Yes
Wallpaper
Yes
Washer / Dryer Prewiring
No
Cargo
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Cargo Area Flooring Type | Vinyl | - | - | - |
| Cargo Area Height | 94 / 2387.6 in | - | - | - |
| Cargo Area Length | 130 / 3302 in | - | - | - |
| Cargo Area Rear Door Style | Ramp Door | - | - | - |
Specs
Buy Now
More
Cargo Area Flooring Type
Vinyl
Cargo Area Height
94 / 2387.6 in
Cargo Area Length
130 / 3302 in
Cargo Area Rear Door Style
Ramp Door
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Skyline Corporation | - | - | - |
| Year | 2009 | - | - | - |
| Make | Skyline | - | - | - |
| Display Name | Layton Way-Lite Ramp Trailer 199 | - | - | - |
| Class | Toy Hauler | - | - | - |
| Max Sleeping Count | 6 | - | - | - |
Specs
Buy Now
More
Parent Company
Skyline Corporation
Year
2009
Make
Skyline
Display Name
Layton Way-Lite Ramp Trailer 199
Class
Toy Hauler
Max Sleeping Count
6
Essential Upgrades for the 2009 Skyline Layton Way-Lite Ramp Trailer 199
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this toy hauler.
Tow-Ready Score
8.0/10
Base Score
5.0
Spec-based adjustments
Based on Toy Hauler class averages
+3.0
Final Tow-Ready Score
8.0
Living Space & Layout
5.5/10
Base Score
5.0
Spec-based adjustments
Based on Toy Hauler class averages
+0.5
Final Living Space & Layout
5.5
Comfort & Features
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Toy Hauler class averages
+0.0
Final Comfort & Features
5.0
Storage Space
6.0/10
Base Score
5.0
Spec-based adjustments
Based on Toy Hauler class averages
+1.0
Final Storage Space
6.0
Off-Grid & Campsites
5.8/10
Base Score
5.0
Spec-based adjustments
Based on Toy Hauler class averages
+0.8
Final Off-Grid & Campsites
5.8
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2009 Skyline Layton Way-Lite Ramp Trailer 199, ensure your vehicle's rated tow capacity exceeds its GVWR of 7750 lbs. With a dry weight of 4625 lbs and hitch weight of 700 lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Toy Hauler has a dry weight of 4625 lbs and a GVWR of 7750 lbs, giving a payload capacity of 2950 lbs for gear, water, and supplies.
The approximate dimensions are length 286 in., width 96 in., and height 138 in. Always confirm clearances for garages, storage, and campsites.
The Layton Way-Lite Ramp Trailer 199 includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many Layton Way-Lite Ramp Trailer 199 owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 7750 lbs and dry weight of 4625 lbs, the Layton Way-Lite Ramp Trailer 199 is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 6 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Toy Hauler.
The Layton Way-Lite Ramp Trailer 199 features body construction with sidewalls and 2 axle(s). Its GVWR of 7750 lbs ensures strength without excessive towing weight.
