2017 Jayco North Point 375bhfs Specs
Can Your Vehicle Tow This?
Interactive towing compatibility checker
Select Your Tow Vehicle
RECOMMENDED TOW VEHICLES
Ford F-250
Up to 22,800 lbs
Ram 2500
Up to 20,000 lbs
Chevy 2500HD
Up to 22,500 lbs
GMC 2500HD
Up to 22,500 lbs
Safe Towing Capacity
80%
Under capacity
Safe zone
Max rating
Essential Upgrades for the 2017 Jayco North Point 375bhfs
Towing & Dimensions
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| GVWR | 16500 lbs | - | - | - |
| Dry Weight | 13740 lbs | - | - | - |
| Hitch Weight | 2790 lbs | - | - | - |
| Payload Capacity | 2760 lbs | Coil SumoSprings | Shop Suspension Kits | - |
| Length | 519 in | Furrion Backup Camera | Shop Cameras | - |
| Width | 96 in | Clip On Mirrors | Shop Mirrors | - |
| Exterior Height | 160 in | Telescoping Ladder | Shop Ladders | - |
| Interior Height | 82 in | - | - | - |
Specs
Buy Now
More
GVWR
16500 lbs
Dry Weight
13740 lbs
Hitch Weight
2790 lbs
Payload Capacity
2760 lbs
Length
519 in
Width
96 in
Exterior Height
160 in
Interior Height
82 in
Towing & Dimensions Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Electrical & Solar
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Battery Converter Amps | 90 | - | - | - |
| Shore Power | 30 Amps | - | - | - |
| Battery Type | 12V Lead-Acid | Renogy 100Ah LiFePO4 | RV Batteries | Top 5 |
| Solar Pre-Wired | Optional | - | - | - |
| Inverter | Optional | - | - | - |
Specs
Buy Now
More
Battery Converter Amps
90
Shore Power
30 Amps
Battery Type
12V Lead-Acid
Solar Pre-Wired
Optional
Inverter
Optional
Electrical & Solar Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tank Capacities
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Fresh Water Holding Tanks | 1 | - | - | - |
| Number Of Gray Water Holding Tanks | 1 | - | - | - |
| Number Of Black Water Holding Tanks | 1 | - | - | - |
| Fresh Water Tank Capacity | 75 gal | - | Fresh Water Tanks | - |
| Gray Water Tank Capacity | 50 gal | - | - | - |
| Black Water Tank Capacity | 50 gal | - | Back Water Tanks | - |
| Number Of Propane Tanks | 3 | - | - | - |
| Propane Tank Capacity | 90 lbs | - | Propane Tank Capacity | - |
Specs
Buy Now
More
Number Of Fresh Water Holding Tanks
1
Number Of Gray Water Holding Tanks
1
Number Of Black Water Holding Tanks
1
Fresh Water Tank Capacity
75 gal
Gray Water Tank Capacity
50 gal
Black Water Tank Capacity
50 gal
Number Of Propane Tanks
3
Propane Tank Capacity
90 lbs
Tank Capacities Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Tires & Wheels
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Rear Wheel Diameter | 16 | - | - | - |
| Spare Tire Location | Exterior Mounted | - | - | - |
| Front Brake Type | Not Applicable | - | - | - |
| Rear Tire | 16 Inch Radial Full Spec | - | - | - |
| Wheels Composition | Aluminum | - | - | - |
| Rear Brake Type | Electric Drum | - | - | - |
Specs
Buy Now
More
Rear Wheel Diameter
16
Spare Tire Location
Exterior Mounted
Front Brake Type
Not Applicable
Rear Tire
16 Inch Radial Full Spec
Wheels Composition
Aluminum
Rear Brake Type
Electric Drum
Heating & Cooling
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Air Conditioning Type | Automatic | Dometic 13.5K Air Conditioner | Shop All RV AC | - |
| Water Heater Tank Capacity | 10 g | RV Tank Water Heater | RV Water Heaters | - |
| Heater Type | Automatic | - | - | - |
| Water Heater Pump Power Mode | Electrical / Propane | - | - | - |
Specs
Buy Now
More
Air Conditioning Type
Automatic
Water Heater Tank Capacity
10 g
Heater Type
Automatic
Water Heater Pump Power Mode
Electrical / Propane
Heating & Cooling Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Living Room / Bedroom(s)
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Sofas | 1 | Tri-Fold Sofa | - | - |
| Master Bedroom Location | Front / Rear | - | - | - |
| Master Bedroom Shades / Curtains | Yes | - | - | - |
| Number Of Bunk Beds | 3 | - | - | - |
| Number Of Recliner / Rockers | 4 | - | - | - |
| Master Bedroom Flooring Type | Carpet | - | - | - |
| Master Bedroom Mirror Doors | Yes | - | - | - |
| Number Of Queen Size Beds | 1 | Queen RV Mattress | Shop Mattresses | - |
| Sofa Material | Vinyl | - | - | - |
| Full Size Master Bedroom Closet | Yes | - | - | - |
| Number Of Bathrooms | 2 | - | - | - |
| Master Bedroom Door Style | Conventional Door | - | - | - |
| Living Area Location | Center | - | - | - |
| Number Of Convertible / Sofa Beds | 2 | - | - | - |
| Reclining Sofa | No | RV Loveseat Recliner Sofa | Shop Sofa | - |
Specs
Buy Now
More
Number Of Sofas
1
Master Bedroom Location
Front / Rear
Master Bedroom Shades / Curtains
Yes
Number Of Bunk Beds
3
Number Of Recliner / Rockers
4
Master Bedroom Flooring Type
Carpet
Master Bedroom Mirror Doors
Yes
Number Of Queen Size Beds
1
Sofa Material
Vinyl
Full Size Master Bedroom Closet
Yes
Number Of Bathrooms
2
Master Bedroom Door Style
Conventional Door
Living Area Location
Center
Number Of Convertible / Sofa Beds
2
Reclining Sofa
No
Living Room / Bedroom(s) Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Kitchen / Dining
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Kitchen Location | Center | - | - | - |
| Refrigerator Size | Full-Size | - | - | - |
| Number Of Oven Burners | 3 | - | - | - |
| Kitchen / Living Area Flooring Type | Carpet / Vinyl | - | - | - |
| Refrigerator Power Mode | Electric / Propane | - | - | - |
| Kitchen Table Configuration | Bench Seats | - | - | - |
| Oven Depth | 21 / 533.4 in | - | - | - |
Specs
Buy Now
More
Kitchen Location
Center
Refrigerator Size
Full-Size
Number Of Oven Burners
3
Kitchen / Living Area Flooring Type
Carpet / Vinyl
Refrigerator Power Mode
Electric / Propane
Kitchen Table Configuration
Bench Seats
Oven Depth
21 / 533.4 in
Bathroom
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Toilet Type | Porcelain | RV Toilet with Sprayer Attachment | Toilets | Top 5 |
| Bathroom Location | Center | - | - | - |
| Bathroom Flooring Type | Vinyl | - | - | - |
Specs
Buy Now
More
Toilet Type
Porcelain
Bathroom Location
Center
Bathroom Flooring Type
Vinyl
Exterior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Awning Length | 17 ft/m | Awning Fabric Replacement | All Awnings | - |
| Number of Awnings | 1 | Motorized RV Awning Set | Shop Awnings | - |
| Leveling Jack Type | Front Power / Rear Power | - | - | - |
| Number Of Axles | 2 | - | - | - |
| Sidewall Construction | Fiberglass | - | - | - |
| Number Of Emergency Exits | 2 | - | - | - |
| Number of Doors | 2 | - | - | - |
| Door Type | Plastic / Glass | - | - | - |
| Body Material | Aluminum | - | - | - |
Specs
Buy Now
More
Awning Length
17 ft/m
Number of Awnings
1
Leveling Jack Type
Front Power / Rear Power
Number Of Axles
2
Sidewall Construction
Fiberglass
Number Of Emergency Exits
2
Number of Doors
2
Door Type
Plastic / Glass
Body Material
Aluminum
Exterior Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Options
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Surround Sound | Yes | - | - | - |
| Cable Prewiring | Yes | - | - | - |
| Phone Prewiring | No | - | - | - |
| Satellite Prewiring | Yes | - | - | - |
| Air Conditioning Prewiring | Yes | - | - | - |
| Wallpaper | Yes | - | - | - |
| Heat Prewiring | Yes | - | - | - |
| Power Retractable Slideout | Yes | - | - | - |
| Sliding Glass Door | No | - | - | - |
| Bunkhouse | Yes | - | - | - |
| Overhead Fan | Yes | Overhead Fan | - | - |
| Refrigerator | Standard | - | - | - |
| Water Heater Tank Bypass | Yes | - | - | - |
| TV Antenna Prewiring | Yes | - | - | - |
| Power Retractable Awning | Yes | - | - | - |
| Screened Room | No | - | - | - |
| Battery Power Converter | Yes | - | - | - |
| Metallic | No | - | - | - |
| Washer / Dryer Prewiring | Yes | - | - | - |
| Interior Wood Finish | Yes | - | - | - |
Specs
Buy Now
More
Surround Sound
Yes
Cable Prewiring
Yes
Phone Prewiring
No
Satellite Prewiring
Yes
Air Conditioning Prewiring
Yes
Wallpaper
Yes
Heat Prewiring
Yes
Power Retractable Slideout
Yes
Sliding Glass Door
No
Bunkhouse
Yes
Overhead Fan
Yes
Refrigerator
Standard
Water Heater Tank Bypass
Yes
TV Antenna Prewiring
Yes
Power Retractable Awning
Yes
Screened Room
No
Battery Power Converter
Yes
Metallic
No
Washer / Dryer Prewiring
Yes
Interior Wood Finish
Yes
Entertainment
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Speaker Location | Interior / Exterior | RecPro Exterior Speakers | - | - |
| Number Of Televisions | 3 | Insignia LED HD Alexa TV | Shop RV TV's | - |
| Number Of Discs | 1 | - | - | - |
Specs
Buy Now
More
Speaker Location
Interior / Exterior
Number Of Televisions
3
Number Of Discs
1
Entertainment Best Sellers
Top-rated products RV owners use to upgrade or maintain their RV.
Instrumentation
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Number Of Radios | 1 | - | - | - |
Specs
Buy Now
More
Number Of Radios
1
Interior
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Material | Vinyl | - | - | - |
Specs
Buy Now
More
Material
Vinyl
Quick Overview
| Specs | Value | Buy | Shop All | Top 5 |
|---|---|---|---|---|
| Parent Company | Thor Industries | - | - | - |
| Year | 2017 | - | - | - |
| Make | Jayco | - | - | - |
| Display Name | North Point 375BHFS | - | - | - |
| Class | Fifth Wheel | - | - | - |
| Max Sleeping Count | 11 | - | - | - |
| Number of Slideouts | 5 | - | - | - |
| Introduction Year | 2016 | - | - | - |
Specs
Buy Now
More
Parent Company
Thor Industries
Year
2017
Make
Jayco
Display Name
North Point 375BHFS
Class
Fifth Wheel
Max Sleeping Count
11
Number of Slideouts
5
Introduction Year
2016
How We Scored This RV
Our MintRV Rating analyzes over 50 specifications across 5 key dimensions. Each dimension starts at 5.0 points and adjusts based on how this RV's specs compare to others in its class. Below is exactly how we calculated each score for this fifth wheel.
Tow-Ready Score
4.5/10
Base Score
5.0
Spec-based adjustments
Based on Fifth Wheel class averages
-0.5
Final Tow-Ready Score
4.5
Living Space & Layout
5.5/10
Base Score
5.0
Spec-based adjustments
Based on Fifth Wheel class averages
+0.5
Final Living Space & Layout
5.5
Comfort & Features
6.3/10
Base Score
5.0
Spec-based adjustments
Based on Fifth Wheel class averages
+1.3
Final Comfort & Features
6.3
Storage Space
5.0/10
Base Score
5.0
Spec-based adjustments
Based on Fifth Wheel class averages
+0.0
Final Storage Space
5.0
Off-Grid & Campsites
5.3/10
Base Score
5.0
Spec-based adjustments
Based on Fifth Wheel class averages
+0.3
Final Off-Grid & Campsites
5.3
About Our Rating Methodology
MintRV Ratings are calculated using verified manufacturer specifications. We compare each RV against others in its class type and weight category. Scores are updated when new specs become available. Learn more about our methodology →
Owner Reviews
No reviews yet. Be the first to share your experience!
Frequently Asked Questions
To safely tow the 2017 Jayco North Point 375bhfs, ensure your vehicle's rated tow capacity exceeds its GVWR of 16500 lbs. With a dry weight of 13740 lbs and hitch weight of 2790 lbs, most midsize trucks and SUVs can tow it comfortably with a 10-20% safety margin.
This Fifth Wheel has a dry weight of 13740 lbs and a GVWR of 16500 lbs, giving a payload capacity of 2760 lbs for gear, water, and supplies.
The approximate dimensions are length 519 in., width 96 in., and height 160 in. Always confirm clearances for garages, storage, and campsites.
The North Point 375bhfs includes a fresh water capacity of gallons, black water tank(s), and lbs of propane capacity-ideal for off-grid weekends.
Many North Point 375bhfs owners add a weight-distribution hitch, brake controller, leveling system, and portable generator to improve towing comfort. Solar kits, backup cameras, and upgraded tires are also popular upgrades.
With a GVWR of 16500 lbs and dry weight of 13740 lbs, the North Point 375bhfs is light enough for smaller tow vehicles yet rugged enough for light off-road travel. Add solar, extra propane, and a generator for extended off-grid stays.
This floorplan sleeps up to 11 people comfortably - perfect for couples or small families seeking a lightweight, easy-tow Fifth Wheel.
The North Point 375bhfs features body construction with sidewalls and 2 axle(s). Its GVWR of 16500 lbs ensures strength without excessive towing weight.
?? Tip: Always check your vehicle's specific towing capacity in the owner's manual. Consider payload and tongue weight too!
As an Amazon Associate, we may earn from qualifying purchases. Your price stays the same.
"Our mission at Mint RV is to help people make well-informed RV buying decisions, so they can escape the stress of everyday life, reconnect with family, and create unforgettable memories in the great outdoors"
